Seams are longitudinal radial separations of the fibers in a tree or log, either open or overgrown with callus tissue. If the seam is overgrown, bark usually is encased. Seams generally are caused by wind, lightning, frost, or injury from falling trees. They are common in trees with cross or spiral grain or that are flanged, fluted, leaning, or internally stressed from other causes such as gelatinous fibers and interlocked grain.

View Slide Show on Seams

Bark Distortion
Bird Peck

Bulge

Bumps
Burls
Butt Scars
Butt Swells
Cankers
Conks
Epicormic Branches
Flanges
Flutes
Forks
Galls
Holes
Knots
Lesions
Limbs
Ring Shake
Rot
Seams
Soak
Splits
Wounds
Significance: The significance of seams depends on their depth and straightness, and on the amount of splintered and fractured wood that is present. A straight seam that results in a single split in the trunk is the least significant. A seam caused by lightning may be accompanied by splintered wood along both sides of the split. This increases the loss in wood volume and prevents the taking of product pieces right up to the edge of the split. A spiral seam causes the greatest difficulty. It results in a degrading effect on two or more faces and contributes to the greater loss of gross log volume. Rot often is associated with a seam and must be considered in the same way as the seam caused by lightning.

In veneer logs, one seam is permitted in the quality zone in logs 15 inches (38.1 cm) and larger in scaling diameter if it diverges from a straight line between the long ends no more than one-half inch per foot (1.3 cm per 30.5 cm) of log length. Such a seam constitutes one standard defect. In all veneer logs 8 1/2 feet (2.6 m) long, the seam can be confined to one face. Additional defects in the log must be treated individually.

In factory logs, a seam with associated rot or fracture that extends into the log for less than one-fifth of its scaling diameter is ignored as a degrader. If it is deeper, even though log scale is reduced, it is still a degrader because it stops cuttings. If a spiral seam extends into a second face, it degrades the log by reducing the required cuttings on the third face. It is mandatory that three log faces fulfill the cutting requirements for a given log grade.

In construction logs, a seam can be overlooked if it enters the largest contained timber (as measured at the small end of the log) only slightly-one-half inch (1.3 cm). If a sound or unsound seam enters the timber more than one-half inch (1.3 cm), it is a log grade defect that degrades the log or causes it to be rejected.

In standing trees, seams create several problems for the timber cruiser. Depth, straightness, and the amount of splintering or accompanying rot are the major factors that must be considered in estimating the effect on tree quality and the class and grade of the logs obtainable from the tree.
